TRAY Sealing Machine VOLVAC E30 - SKINPACK
VOLVAC E30 is one of our Full Automatic Tray Sealer models. Since it can be used with wheels, it can be shipped to the desired location very easily and vacuum packaging processes can be started immediately. Vacuuming process time is between 15 – 25 seconds.
Full automatic traysealer E30 has been developed in accordance with the design of traysealers. Machine dimensions are 917x2890x1765 h mm. It can pack between 360-480 cyle and 720-960 per hour. Pump capacity is 100 and 150 m³. The top film wrap is 460 mm wide. It can process 2 pieces of 190x144x80 plate molds used as standard.
Full automatic bowl sealing machine E30 is the model that is ordered by customers, which is generally recommended for mass production vacuum packaging processes. It is a very useful model thanks to its normal and large dimensions due to the large number of products to be vacuumed.
Video Gallery
| Warranty | 3 YEARS |
| Pump Capacity | 150 m³ / h (7 kW) |
| Cycle | 3 - 10 cycle/minute |
| Product Capacity | 360 packages/hour - 1,200 packages/hour |
| Pneumatic System | SMC |
| Electric Switch | OPAŞ |
| Control Panel | VOLVAC touch panel (SCHNEIDER) |
| Block Piston | 160 x 180 steel alloy piston |
| Chassis Series | 7000S aluminum chassis series |
| Warranty | 2 YEARS |
| Pump Capacity | 105 m³ / h (5.5 kW) |
| Cycle | 2 - 10 cycle/minute |
| Product Capacity | 240 packages/hour - 1,200 packages/hour |
| Pneumatic System | PEMAKS |
| Electric Switch | OPAŞ |
| Control Panel | VOLVAC touch panel (SCHNEIDER) |
| Block Piston | 125 x 180 aluminum alloy piston |
| Chassis Series | 7000 aluminum chassis series |
| Machine Dimensions | 900 x 2890 x 1830 h mm |
| Weight | 590 kg |
| Film Wrap | with encoder system |
| Top Film Width | 460 mm |
| Security System | IP63 protection class |
| Gas Kit | available |
| Memory Capacity | 99 pcs |
| Air Consumption (1 cycle) | 35 liters |
| Vacuum Value | 0.1 mbar |
| Pneumatic Feed | 16 NI/6-8 bar |
| Power | 36A -400v 50 Hz |
| kW | 5.5 kW |
| Certificate | CE |
| External Mold | stainless steel AISI304 |
| Cleaning | totally design that provides hygienic cleaning convenience |
| Security System | safety switch available |
| Film Playing System | |
| td> | SERVO motor |
| Emergency Stop Button #1 | product loading area (1 unit) |
| Emergency Stop Button #2 | control panel protection (1 pc) |
| Lifting Unit | pneumatic mold lifting system driven |
| Container Unit | easy replace |
| Clue Valve | pressure controlled |
| Residue Unit | specially designed |
| Vacuum Sensor | available |
| Temperature Control System | available |
| Container Unloading Station | available |
| Cut & Paste Station | available |
Bu kaynak metin hakkında daha fazla bilgiEk çeviri bilgileri için kaynak metin gerekli
Geri bildirim gönder
Yan paneller
| 95 x 125mm | 3 pcs |
| 190 x 144mm | 2 pcs |
| 227 x 178mm | 2 pcs |
| 325 x 265mm | 1 pc |
